125I Solid-Core Metering Class Current Transformers

Model# 125I 600V

Download Datasheet

Download Product Catalog

Manufactured to meet requirements of UL 1244 and revisions.
Model 125I Terminals are Brass Studs No. 8-32 UNC
Mounting Brackets: P/N 0221B00231
Bus Bar Mounting Kit: P/N 0221A26076
For use with AGW series and AGH series Watt and Watt/Watt Hour Transducers.
Ideal for use with Ammeters, Set Point Relays, Watt, Var, Current Transducers and Watt Hour Meters.

Insulation Class0.6kV, 10kV BIL Full Wave

Weight3 Lbs

1600:5 thru 5000:50.2%

Amps0-1600 thru 0-5000A

Frequency50-400Hz

Standard5A

Detailed Model Specifications

Click below to see available detailed specifications

While these tables work on mobile devices, they are best viewed on a desktop computer.

5 AMP Secondary Models

Catalog Number	Input Amps	Output Amps	Accuracy	VA Rating	Secondary Winding Resistance(Ω@75°C)	@30°C	@55°C	Weight
125I-162	1600A	5A	0.2%	10	0.304	1.5	1.33	3 Lbs
125I-202	2000A	5A	0.2%	12	0.280	1.5	1.0	3 Lbs
125I-252	2500A	5A	0.2%	20	0.351	1.33	1.0	3 Lbs
125I-302	3000A	5A	0.2%	20	0.421	1.33	1.0	3 Lbs
125I-402	4000A	5A	0.2%	30	0.696	1.0	0.8	3 Lbs
125I-502	5000A	5A	0.2%	40	1.220	1.33	1.00	3 Lbs
