Model# SCT-0400 600V Class

AC Split-Core Current Transformers

Shipping / Availability

Shipping / Availability: 1 - 2 Week Lead Time

The SCT-0400 AC Split-Core Current Transformers “sense” AC current from 5 to 75 Amps passing through the window. These transformers are ideal for installation on existing electrical wiring by snapping around the conductor. The SCT series has the highest industry standards for interleaving joints and the self-locking mechanism.


Phase Angle < 2 degrees (valid 20A or higher)
Weight3 oz


±1%@ 10% to 130% of rated current


Amps0-5A thru 0-75A
Frequency50Hz to 400Hz



SCT-0400 Split-Core Current Transformers

  • RoHS

  • CE

  • C RU US
